Purelyst® PH-302

Purelyst® PH-302 제품명, 제거대상, 특징, 적용분야에 완련된 표
Product name	Purelyst® PH-302
Targeted pollutants	CO Various odorous substances and volatile organic compounds(VOCs)
Characteristics	Maintains catalytic performance even with sulfur dioxide and halogen compounds High support coating amount High dispersion of catalytic components Can be combined with pre-treatment agent and honeycomb filter
Applicable fields	Semiconductor, display manufacturing processes Coating, petrochemical, printing factories Sludge drying process, odor-generating process

Purelyst® PH-302 제품규격(촉매활성성분, 지지체/셀 형태, 내구온도(℃), 셀 밀도(cells/in2), 크기(mm),셀 수(ea), 셀 피치(mm) ,셀벽 두께(mm), 오프닝(%), 접촉면적(m2/m3) , 촉매 성분 코팅량(g/in3))에 완련된 표
Item	Content
Catalyst active component	Pd, Pt
Support/Cell shape	Cordierite / Honeycomb
Endurance temperature(℃)	500
Cell density(cells/in²)	75	100	200
Size(mm)	150×150×50/100	150×150×50/100	150×150×50/100
Number of cells(ea)	2,601(51×51)	3,364(58×58)	6,889(83×83)
Cell pitch(mm)	2.94	2.59	1.81
Cell wall thickness(mm)	0.6	0.45	0.36
Opening(%)	63.3	62.2	58.3
Contact area(m²/m³)	1,082	1,220	1,690
Catalyst component coating amount(g/in³)	1.7 ± 0.2	1.7 ± 0.2	1.7 ± 0.2
