Purelyst® PH-304

Usage

Purelyst® PH-304 제품명, 제거대상, 특징, 적용분야에 완련된 표
Product name Purelyst® PH-304
Targeted pollutants
  • CO, CH4, H2
  • Various odorous substances and volatile organic compounds(VOCs)
Characteristics
  • Possesses thermal stability up to 950℃
  • Resistant to HCl, SO2
  • Improves the exhaust efficiency of the facility by installing a small amount of catalyst in the existing RTO
  • Does not generate thermal NOx
  • Applicable to various metal substrates such as metal foam and metal honeycomb
Applicable fields
  • Safe oxidation of emergency hydrogen in nuclear power plants
  • Removal of VOCs with high boiling points generated from wire varnish coating machines
  • Coating, petrochemical, printing factories
  • Sludge drying process, odor-generating process

Product specifications

Purelyst® PH-304 제품규격(촉매활성성분, 지지체/셀 형태, 내구온도(℃), 셀 밀도(cells/in2), 크기(mm),셀 수(ea), 셀 피치(mm) ,셀벽 두께(mm), 오프닝(%), 접촉면적(m2/m3) , 촉매 성분 코팅량(g/in3))에 완련된 표
Item Content
Catalyst active component Pt, Pd 계
Support/Cell shape Cordierite / Honeycomb
Endurance temperature(℃) 950
Catalyst name PH-304 PH-304MF PH-304MH
Form Honeycomb Metal foam Honeycomb
Material Cordierite NiCr, etc. FeCrAl
Specifications Size(mm) 150×150×50/100 Standard : 165×50×5(Cutomizable) 150×150×50(Cutomizable)
Cell density(cells/in2) 75 ~ 200 - 15 ~ 400
Cell wall thickness(mm) 0.6 - 0.06, 0.08
Pore size(mm) - 0.45 ~ 1.20 -
Cell shape - Porous irregular Hexagonal, wave-shaped

Product image

  • Purelyst® PH-304
  • Purelyst® PH-304MF
  • Purelyst® PH-304MH
